Sparkling Clear Industries (SCI) recently installed a water softener for a critical application in a Gulf Coast area chemical plant salt dome operation. This duplex alternating system supplies scale free and soft water to protect and lubricate brine pump seals.
A NEMA 4X enclosure contains the 3200NXT controller and respective stager. The controller will display Service, Standby or Regeneration steps. The softener will operate as a duplex alternating system with lockout to prevent the simultaneous regeneration of the two softeners.
A single Hall Effect flow sensor will monitor the effluent flow in a common header. The NEMA 4X enclosure will also contain a Signet Model 8550 flow transmitter with local display and 4-20 mA output.
Differential Pressure Monitoring is also included with programmable set points and 4-20 mA output.
The face piping for this system includes SS316 threaded ball valves with air actuated operators, schedule 80 SS316 pipe and SS316 3000# threaded fittings, conforming to the customers specifications.
A Polyethylene Bulk Brine Storage Tank with a 10,000 Gallon Capacity completes the system.
The project was managed by the SCI office located in Clute,Texas. The excellent working relationship between the customer and SCI resulted in a project that met the customer’s requirements and was on-time. For more information, contact us today.
