Strainers

Elbow Strainers

  • Elbow strainer for tight piping installations downstream equipment protection.
  • Economically designed to meet many application requirements.
  • Flow may be in either direction with a perforated screen. Mesh lined screen must specify the flow direction.
  • The screens are similar to that of a “Y” strainer.
  • Available with butt weld or flanged ends as a standard design.
  • Elbow strainers will not be hydro tested, but will be checked by NDE (non-destructive examination)



OPTIONS



  • High pressure and temperature ratings
  • Differential pressure switches and gauges
  • ASME Code “U” Stamp
  • Vent and Drain Valves
  • Other materials available for corrosive environments
  • Other sizes available upon request



305/307 vs 305HF/307HF (High Flow)
The High Flow has a larger body size thus making the dimensions
larger. The High Flow models will have a concentric reducer added.
